92 Setting Up Your Local Area Network
Communicating with the Magnia SG30
5.375 x 8.375 ver 2.1
disk. As a result, data may be lost, and the system could even
become inoperable.
Viewing LCD information
The LCD panel can display a variety of information about
your Magnia SG30. The default display shows the date and
time. Several messages may be displayed simultaneously, in
which case some messages appear only when you scroll
through the list of messages.
You can press the Status scroll button on the front of the
appliance to view the Internet IP address and other current
status information.
Urgent messages will display on the LCD panel immediately:
they don’t require use of the scroll button.
To set the LCD to display the status of certain system
conditions:
1 From the Administration Web site, select the System tab,
and click the LCD Panel tab.
The LCD options screen appears.
2 Select which options you want to display on the LCD and
click Apply.
Some of the information on the LCD panel is always displayed
and cannot be turned off. This information includes:
❖ Private address: This private TCP/IP address is set for
the local network Ethernet interface (7 port hub).
❖ Public address: This public TCP/IP address is set for the
public (Internet) Ethernet port.
❖ Time of day: This default display is frequently used to
show the system is ready.
Other information can be displayed on the LCD panel. This
optional information includes:
❖ Firewall status: This displays the status of firewall
operation.
