25 Getting Started
Finding your way around
5.375 x 8.375 ver 2.1
Finding your way around
This section explains the physical connections and screen
displays of the Magnia SG30.
Front of the Magnia SG30
Locating the LCD display, status and power buttons
❖ The LCD display indicates that the Magnia SG30 is on,
provides access to the public and private network IP
addresses, and displays warnings if any of the hardware
is at the point of failure.
You can configure the display to provide information
about the status of your Magnia SG30 such as: modem
status, the date and time the last backup was performed,
the availability of software upgrades, and so on.
❖ The Status scroll button allows you to scroll through the
information displayed on the LCD display.
❖ The Power/Shutdown button turns the Magnia SG30 on
and off. When you turn off the Magnia SG30, a message
prompts you to press the button again as confirmation.
LCD display
Status scroll button
Power/Shutdown button
