176 Managing the Server
Using the second disk drive
5.375 x 8.375 ver 2.1
2 Turn off the Magnia SG30 by pressing the
Power/Shutdown button on the front of the unit, or by
using the system shutdown feature of the Administration Web
site, and disconnect the power cable.
3 Undo the thumbscrew on the rear of the
Magnia SG30.
4 Slide back the top of the case.
5 Locate the slot for the disk drive. Facing the unit from the
front, the primary disk drive slot is on the right, and the
secondary disk drive slot is on the left.
6 If you are replacing a primary disk drive:
❖ Remove it by unscrewing the thumbscrew.
❖ Slide the disk drive back and lift it out.
❖ Remove the drive from the disk drive from the drive
cage by unscrewing the four mounting screws.
❖ Continue at step 8 .
7 If you are adding a new disk drive, mount the new disk
drive to the drive cage using the screws.
8 Install the new disk drive in the chassis.
(Again, facing the machine from the front, the primary
drive is on the right, and the secondary drive is on the
left.)
Place the disk drive on the rails and slide it forward.
Ensure that the disk drive connectors engage firmly with
the chassis connectors.
