Product Description
18
Hardware Features
The following sections describe these hardware features of the
AT-WL2411 Access Point:
❑ Status LEDs
❑ 10 Mbps twisted pair Ethernet port
❑ Serial connection management port
❑ Serial connection management cable
❑ 5V DC power supply input port
❑ External AC/DC power adapter
Status LEDs The AT-WL2411 features the following status LEDs:
❑ Power
❑ Radio
❑ Wired LAN: Ethernet link and activity
❑ Root/error
Figure 1 illustrates the four LEDs on the AT-WL2411.
Figure 1 System LEDs
Power
Radio
Wired
LAN
Root/error
21XXT031.eps
