AT-WL2411 Version 1.80 Installation and User’s Guide
175
Radio
LEDs If the radio is faulty or the configuration matrix string is incorrect, the
LEDs on the access point display the following pattern, as shown in
Table
9 , after the access point boots.
Table 9 Radio LEDs
Communication
s Program or
Telnet
If you are connected to the access point through a serial connection, an
error message also appears on your terminal or PC. The error messages
are described in
Table 10 .
Table 10 Serial/Telnet Error Messages
Power Radio Wired LAN Root/Error
ON OFF ON ON
Error Message Explanation
Couldn’t read country code from
radio The radio may be faulty. Contact
your Allied Telesyn representative.
Radio A has unknown country
code The radio may have been
configured incorrectly at the
factory. Contact your Allied
Telesyn representative.
Invalid country code in string for
radio The country code in the
configuration matrix string does
not match the country code in the
radio in the access point. Contact
your Allied Telesyn representative.
Radio string doesn’t match radio
installed When this error message appears,
additional information also
appears on the screen. The radio
may be faulty. Contact your Allied
Telesyn representative.
