Configuring the IEEE 802.11b Radio
112
Using One AT-WL2411 in a Simple Wireless Network
You can use the AT-WL2411 to extend your existing Ethernet network to
include wireless end devices. The access point connects directly to your
wireless network and the end devices a wireless extension of the wired
LAN.
Figure 39 A Simple Wireless Network
In a simple wireless network, the access point that is connected to he
wired network serves as a transparent bridge between the wired
network and wireless end devices.
To install a simple wireless network, perform the following procedure:
1. Configure the initial IP address. For help, refer to Configuring the
TCP/IP Settings on page 52.
2. Install the access point. For help, refer to Installation on page 25.
3. Configure the Ethernet network. For help, refer to Configuring the
Ethernet Network on page 51.
4. Configure the radios. For help, refer to To Configure the 802.11b
Radio on page 127.
H ost
Access
Point
Ethernet
