Troubleshooting
174
LEDs
When the access point is powered ON, the LEDs flash as the access point
boots and performs internal diagnostics.
Table 7 describes the LED
activity during the boot process.
Table 7 Boot-up LED Activity
Table 8 displayes the LEDs of the access point after a successfully boot-
up.
Table 8 After Boot-up LED Activity
Power Radio Wired LAN Root/Error Description
ON OFF OFF ON Flash checksum
being calculated.
ON ON OFF ON Flash checksum
failure.
ON OFF ON OFF RAM test in
progress.
ON ON ON OFF RAM test failure.
ON OFF OFF OFF Monitor loading in
progress.
ON OFF OFF ON Ethernet test in
progress.
ON ON OFF ON Ethernet test failure
Power Wireless #1 Wired LAN Root/Error
ON Flashes Flashes Flashes if the
access point is
configured as
the root.
