AT-S85 and AT-S97 Management Software Command Line Interface User’s Guide
235
The fields are defined here:
Slot ID: A slot in the chassis. Possible values are:
– C: Indicates the chassis.
– M: Indicates the management slot for the
AT-MCF2000M Management Module.
– number: A media converter slot number (for example,
1, 2, etc.). Empty slots are not included in the tables.
Note
The AT-MCF2000S Stacking Module is not displayed.
Module Name - Indicates the name of the module. Refer to “SYSTEM
SET MODULE” on page 86 for instructions on assigning a name to a
module.
Module Type - Indicates the model name.
MAC Address - Indicates the chassis or module’s MAC address.
Software Version - Indicates the version number of the AT-S85 and
AT-S97 software.
Example
This command displays the version number of the bootloader software:
diagnostics show software
