Chapter 9: Configuration File Commands
150
The section is prefaced with three header lines that identify the media
converter module in the chassis controlled by the commands in the
section. An example is shown in Figure 30.
Figure 30. Blade Configuration Header
The Filename line identifies the name of the auxiliary configuration file
used to create that portion of the master file as well as the media converter
module controlled by the commands. The numbers in the filename identify
the module. The first number represents the chassis ID and the second
number the slot number. For example, the auxiliary configuration filename
“BM_0_2.cfg” in Figure 30 identifies the media converter module in slot 2
of the chassis with an ID number of 0.
The Model Type field specifies the model name of the media converter
module and the MAC Address specifies its MAC address.
Note
The header lines of a Blade Configuration section should not be
modified or deleted.
The first subsection in a Blade Configuration is illustrated in Figure 31. It
sets the operating modes of the media converter channels on the module
with a modified version of the SYSTEM SET INTERFACE command. The
ID parameter of the command is replaced with a PORTID parameter,
which specifies the channel number. For example, PORTID=1 designates
channel 1, which on the AT-MCF2012LC and AT-MCF2012LC/1 Media
Converter Modules represents twisted pair port 1 and fiber optic port 1,
PORTID=2 designates channel 2 of twisted pair port 2 and fiber optic port
2, and so on.
Figure 31. Blade Configuration - Operating Mode Section
## Filename: BM_0_2.cfg
## Model Type: AT-MCF2012LC
## MAC Address: 00:15:77:70:7A:2C
### Blade Configuration
system set interface portId=1 OpMode=link-test
system set interface portId=2 OpMode=link-test
system set interface portId=3 OpMode=link-test
system set interface portId=4 OpMode=link-test
system set interface portId=5 OpMode=link-test
