Chapter 6: Port and Module Commands
106
Figure 15. SYSTEM SHOW INTERFACE Command - Chassis ID, Slot ID,
and Channel
The fields are defined here:
ˆ Interface Information - The location of the channel. The information is
given as chassis number, slot number, and channel number.
ˆ Chassis ID - The ID number of the chassis.
ˆ Slot ID - The slot number in the chassis with the media converter
module. In the AT-MCF2000 Chassis, the left slot is 1 and the right slot
is 2.
ˆ Module Name - The name of the module. To assign a name, refer to
“SYSTEM SET MODULE” on page 86.
ˆ Module Type - The module’s model name.
ˆ Port Name - The channel’s name. The default is “User Port.” This
parameter cannot be changed.
ˆ OpMode - The operating mode of the channel, which can be
MissingLink, Smart MissingLink, or Link Test. For a description of the
operating modes, refer to “SYSTEM SET INTERFACE” on page 79.
Interface 0/2/7 Information
Chassis ID ............... 0
Slot ID .................. 2
Module Name .............. User Module
Module Type .............. AT-MCF2012LC
Port Name ................ User Port
OpMode ................... Link Test
Port Copper Link
Port State .......... Enabled
Link Status ......... Online
Auto Negotiation .... Enabled
Speed ............... 100 Mbps
Duplex .............. Full
MDI Crossover ....... MDI
Ingress Rate Limit .. No Limit
Egress Rate Limit ... No Limit
Port Fiber Link ....
Port State .......... Enabled
Link Status ......... Online
Speed ............... 100 Mbps
Duplex .............. Full
Ingress Rate Limit .. No Limit
Egress Rate Limit ... No Limit
