Chapter 6: Port and Module Commands
110
Figure 17 illustrates the information for the management Module.
Figure 17. SYSTEM SHOW MODULE Command for the Management
Module
The information for the AT-MCF2012LC and AT-MCF2012LC/1 Media
Converter Modules is shown in Figure 18.
Figure 18. SYSTEM SHOW MODULE Command for a Media Converter
Module
The fields are defined here:
ˆ Module Name - The name of the module. Refer to “SYSTEM SET
MODULE” on page 86 for instructions on assigning a name to a
module.
CPU Information:
Name .......................
Module Type ................ AT-MCF2000M
Module Status .............. Active
Module Present ............. Present
1.2V ....................... Good = 1.212V
1.8V ....................... Good = 1.818V
2.5V ....................... Good = 2.535
3.3V ....................... Good = 3.336V
12.0V ...................... Good = 12.187
Temperature ................ 29.2500 C
Temperature Threshold ...... 60 C
Management Port:
Link State ........... Up
Auto Negotiation...... Enabled
Speed ................ 100 Mbps
Duplex ............... Full
MDI Crossover ........ MDI
Stacking Port:
Link State .......... Up
CPU Information:
Name .......................
Module Type ................ AT-MCF2012LC
Module Status .............. Active
Module Present ............. Present
1.2V ....................... Good = 1.198
1.8V ....................... Good = 1.804V
2.5V ....................... Good = 2.509
3.3V ....................... Good = 3.302V
12.0V ...................... Good = 12.6224
Temperature ................ 38.15V
Temperature Threshold ...... 60 C
