2. In the upper pane of the Drive Cages screen, click the Summary tab and then click a drive
cage.
3. In the lower pane, click the Summary tab.
The details Summary tab appears as follows:
The following information is provided:
Description Field Group
The drive cage name. Name General
The drive cage model. Model
The World-Wide Name of the controller node. Node WWN (for DC1 and
DC3 drive cages)
The drive cage serial number. Serial Number (for DC3 drive
cages)
Whether the drive cage is in split loop mode. Split Loop (for DC2 and DC4
drive cages)
The number of ID switches. ID Switch (for DC3 drive
cages)
The number of interface cards. Interface Cards
The number of SFPs. SFPs
The number of drive magazines. Magazines
The number of available drive magazine bays. Free Drive Bays
The number of physical disks. Physical Disks
The number of power supplies. Power Supplies
The location of the drive cage. Location
The throughput in KB/sec for the Loop A port. Loop A Resources
The throughput in KB/sec for the Loop B port. Loop B
Revision of firmware running on the FC-AL for port A. Loop A Connectivity
Controller node initiator port connected to drive cage port A0. A0 Port
Controller node initiator port connected to drive cage port A1. A1 Port
78 Working with Drive Cages
