The following information appears in the lower tab:
Description Field Group
Interface card number, as assigned by the
system. Interface Card General
SFP number, as assigned by the system. SFP
Current condition of the SFP. State
Manufacturer of the SFP. Manufacturer
Part number of the SFP. Part Number
Serial number of the SFP. Serial Number
SFP's revision level. Revision
Maximum speed allowed by the SFP. Max Speed
Displays whether the SFP has been tested
and if the SFP is supported. Qualified
Displays whether the transmit laser is
disabled. TX Disable
Displays whether the transmit laser has a
problem. TX Fault
Displays whether the receive end of the SFP
is experiencing a loss of signal from the host
or drive cage. RX Loss
Displays whether the SFP receive power is
low. RX Power Low
Displays whether the SFP is DDM-capable
(Digital Diagnostic Monitoring). DDM Support
Description Column
Identifies the monitored parameters
(temperature, voltage, TX bias, TX power,
and RX power). Type DDM
The unit of measure used for the monitored
parameters. Unit
The current measured value. Value
The manufacturer's recommended lower-limit
warning level. Low Threshold Warning
The manufacturer's recommended upper-limit
warning level. High Threshold Warning
The manufacturer's recommended lower-limit
alarm level. Low Alarm Threshold
The manufacturer's recommended upper-limit
alarm level. High Alarm Threshold
Viewing Drive Cage Alerts
To view the Drive Cage alerts:
1.
Access the Drive Cages screen.
2. In the upper pane, click the Alerts tab.
The Alerts tab appears as follows:
76 Working with Drive Cages
