12 Logging In and Connecting to Systems
The InForm Management Console allows authorized users to connect to a system, or to multiple
systems. In order to connect to system, you must have the following information:
•
System name or IP address
•
Username
•
Password
To connect to a system:
1.
Start the InForm Management Console.
NOTE: Any systems previously connected to are displayed in the text box under the IP
Address or Name text box. To select multiple systems use CTRL+click.
2. In the Connect dialog box, enter:
a.
the IP address or system name.
b. your user name.
c. your password.
3. If you do not want a secured connection, uncheck the Secure Connection checkbox. Otherwise,
click OK.
4. By clicking Options, you can modify the Secure Data Port, Unsecured Data Port, and Event
Portcheck boxes as needed.
NOTE: A Secure Data Port is not a valid integer message will appear if attempting to log into
multiple systems at once with different secure data ports. Systems with different secure data ports
must be connected to one at a time.
