Raw capacity for the selected system is displayed for Total, Fibre Channel, Near Line, and Solid
State capacities. Each of these top level capacity items can be further expanded to the following:
NOTE: In the normal situation, the capacity displays show you the space that is consumed by
provisioning (e.g. CPGs, Volumes, and underlying LDs) and the space that is reserved by the system
for spares.
When chunklets or PDs fail, the data that was on those chunklets is moved onto the spares. The
total amount of space consumed by provisioning does not change, nor does the total amount of
spares in the system. However, there is an overlap in the numbers because the used spares are
counted in the total number of spares (total spares = unused + used spares) AND in the provisioning
(because parts of the LDs/CPGs/Volumes) are now using those spares. In this case, an asterisk
(*) appears to indicate that the numbers will not add up due to this shared space.
Description Field
Total amount of usable storage on the system. + Total
Amount of storage capacity currently allocated. + Allocated
Amount of storage allocated to volumes. + Volumes
Amount of volume space allocated to base volumes. + Base Volumes
Amount allocated for base volume user space, copy space and
admin space. - User
- Copy
- Admin
Amount of volume space allocated to CPGs. + CPGs
Amount of CPG space allocated to Copy. + Copy
Amount of Copy space that is used or not used. - Used
- Unused
Amount of CPG space allocated to admin. + Admin
Amount of admin space that is used or not used. - Used
- Unused
Amount of volume space that is not mapped. - Unmapped
Amount of allocated space used by the system. + System
Amount of system space used internally. - Internal
Amount of space allocated to spares. + Spares
Spare space allocated for LDs when underlying PDs have failed. - Used
Unused space. - Unused
Amount of free space on the system, regardless of initialized or
not. + Free
Amount of initialized free space on the system. - Initialized
Amount of uninitialized free space on the system. This includes
any chunklets that are currently being cleaned. - Uninitialized
Amount of failed space. - Failed
Total amount of Fibre Channel (FC) storage on the system. + Fibre Channel
NOTE: Subcontents of the Fibre Channel Total display are identical to the Total display at the top of this table.
