Description Field Group
Rate that data can be transferred over the port (1 Gbps, 2 Gbps
or 4 Gbps). When there is no specified value, no connection
exists. Rate
Type of device that the port is connected to. Free, Disk, Host,
Peer, or InServ. Connected Device Type
Name of device that the port is connected to, e.g. host1, cage0. Connected Device
Port firmware mode setting. Ports in Initiator mode are connected
to drive cages and ports in Target mode export to hosts. Mode
Suspended mode is for target ports that have not yet been
initialized by the system (rare). Peer mode is for Ethernet ports.
Current state of the port. State
The Media Access Control address for the Ethernet interface. MAC IP Settings
IP address of the RCIP port. IP Address
The address of a local IP router on the same network as the
system, used to forward traffic to destinations beyond the local
network. Gateway
Netmask address for the RCIP interface. Subnet Mask
Maximum Transmission Unit. The greatest amount of data or
"packet" size that can be transferred in one physical frame on MTU
a network. MTU setting for the iSCSI port. The default setting is
1500. When supported by the network, an MTU value of 9000
should be used.
The duplex speed, Half or Full. Configured Rate
Model of the adapter that contains the port (for example, Intel
PRO/1000MT). Duplex
The TCP port number used by the iSCSI or RCIP card. Adapter Type
The throughput in KB/sec. Total Data Throughput Resources
Viewing SFP Information
To view port SFP information:
1.
Access the Ports screen.
2. In the Management Window, click the SFPs tab.
The SFPs tab appears as follows:
