388 Disk Enclosure Modules

Figure 94

Disk Module Removal

Installing

a Disk Module or Filler Module

C

AUTION

Touching the disk circuit board can cause high energy
discharge and damage the disk.

Disks modules are fragile and should be handled carefully.

A ESD plug-in
B cam latch
C handle
