26 Disk Enclosure Components

Figure 3

Disk Enclosure Front and Back View

Power Switch

The power switch (B in

Figure 3

) interrupts power from the power supplies to the disk

enclosure components. Power to the power supplies is controlled by the power cords and
the AC source.

A system LEDs
B power button
C disk module
D disk module LEDs
E door lock
F ESD plug
G mounting ear
H power supply
I BCCs
J fans
K component LEDs
