Installing the Disk Array FC60 155
Inst
alla
tion
Installing the Disk Array FC60
Note
The A5277AZ factory assembled disk array is fully configured and requires only
connection to the host. Proceed to
"Connecting the Fibre Channel Cables" on
to complete the installation. Do not remove any of the factory installed
disk enclosures before powering on the disk array, or the disk array will not
function properly.
If the factory default Fibre Channel address settings (4 and 5) will not work, the
settings can be changed as described in
"Fibre Channel Host ID Address
Installation of the Disk Array FC60 consists of installing the controller enclosure and up to
six disk enclosures. Before performing this installation you should have determined the
configuration for the array (as described in chapter 2, Array Planning and Topology). You
should also review this section prior to performing the installation.
The Disk Array FC60 is supported in the System/E racks and in the HP legacy (original)
cabinets.
Note
The HP SureStore E Disk Array FC60 has been tested for proper operation in
supported Hewlett-Packard cabinets. If the disk array is installed in an untested
rack configuration, care must be taken to ensure that all necessary
environmental requirements are met. This includes power, airflow,
temperature, and humidity. Failure to meet the required operating
specifications may result in product failure.
