Verifying Disk Array Connection 209
Inst
alla
tion
The port value will always be 255 when using PDA. The loop address, Fibre Channel Host
ID of the disk array controller module (two address possible, one for controller module A
and one for module B), is encoded in the Bus and Target segments of the hardware path.
For example, in the hardware path shown in
Figure 80 , the Bus value of 1 and Target value
of 2 result in a loop ID of 18:
BUS TARGET LOOP ID
0 0 0 1 0 0 1 0 = 18
Volume Set Addressing
Volume set addressing (VSA) is used to address disk array LUNs. A disk array LUN can be
identified in the ioscan output as an entry with a driver type of
sdisk
and a description of
HP A5277A. The LUN number is encoded in the Volume Number segments of the hardware
path.
Figure 81 illustrates the interpretation of the fields in the hardware path when using VSA.
Figure 81 Volume Set Addressing Hardware Path
8/12.8.0.6.0.1.3
Bus Converter
Adapter
Protocol Type (8 = mass storage)
Loop ID of controller module
Volume Number bits 7 - 13 (always 0 for the FC60)
Volume Number bits 3 - 6 (virtual SCSI bus 0 - 3)
Area (0 = point-to-point or private loop)
Volume Number bits 0 - 2 (LUN number 0 - 7)
Volume Set Addressing (VSA) Hardware Path
