Status Conditions and Sense Code Information 319
M
a
na
ging
the
Di
sk
Array
on HP-UX
Disk Status Conditions
The disk status condition terminology used by Array Manager 60 (AM60) may differ from
that used by STM. Both terms are identified in the table.
Table 41 Disk Status Conditions
Status Definition/Action
AM60: OPTIMAL
STM: OPTIMAL (OPT) The disk is operating normally.
No action is required.
AM60: NON-EXISTENT
STM: No Disk (NIN) The disk array controller has no knowledge of a disk in this
slot. This may be caused by no disk being installed, or a disk
that never responds to a SCSI command from the controller.
No action is required.
AM60: UNASSIGNED
STM: OPTIMAL (OPT) The disk is a member of the unassigned disk group. It is
available for use in a LUN or as a hot spare.
No action is required.
AM60: FAILED--CAUSE
UNKNOWN
STM: FLT - 3 The disk has failed due to an unknown condition.
Replace the disk.
AM60: REPLACED
STM: OFF - 4 The disk has been replaced. The disk will maintain this status
until the original data has been rebuilt or copied to the disk.
No action is required.
AM60: WRONG DRIVE
REMOVED OR REPLACED
STM: FLT - 9 The wrong disk was removed or replaced from a degraded
LUN. The new disk gets this status.
Reinstall the original disk.
AM60: OFFLINE--
INTERNALLY MARKED OUT
OF SERVICE
STM: OFF - 11 A disk has been installed that was part of another LUN,
possibly in another disk array. The disk array attempts to
recreate the original LUN, but because some of the disk are
missing, the disk is marked OFFLINE. The newly created LUN
will also be assigned a status of DEAD.
Unbind the LUN the disk array has created. This will return the
disk to UNASSIGNED status.
AM60: NON-SUPPORTED
CHANNEL
STM: FLT - 17 The command issued specified an invalid channel.
Retry the command using the proper channel.
