74
4. XSEL-R/S/RX/SX/RXD/SXD
4.5 Standard I/O Ports of XSEL Controller
For the standard I/O ports of XSEL controller, it is possible to change the specified functions except for
the general-purposed I/O with the I/O parameters. [Refer to the instruction manual for the XSEL-P8/Q8
controller for more information.]
ƔSettings of Standard I/O Ports at Delivery
Input Port Output Port
Port No. Function Port No. Function
000 Program Start 300 Alarm Output
001 Universal Input 301 Ready Output
002 Universal Input 302 Emergency Stop Output
003 Universal Input 303 Universal Output
004 Universal Input 304 Universal Output
005 Universal Input 305 Universal Output
006 Universal Input 306 Universal Output
007 Program
Specification
(LSB) 307 Universal Output
008 Program
Specification
308 Universal Output
009 Program
Specification
309 Universal Output
010 Program
Specification
310 Universal Output
011 Program
Specification
311 Universal Output
012 Program
Specification
Startup
program to
be indicated
with binary
312 Universal Output
013 Program
Specification
(MSB) 313 Universal Output
014 Universal Input 314 Universal Output
015 Universal Input 315 Universal Output
ᰳ
ᰳᰳ
ᰳ
ᰳᰳ
ᰳ
ᰳᰳ
ᰳ
ᰳᰳ
Note The number of standard I/O ports is;
Ɣ
Input 000 to 299 (MAX 300 points )
Ɣ Output 300 to 599 (MAX 300 points )
Be careful of the number of I/O ports when using CC-Link and PIO together.
For the standard I/O ports of XSEL controller, it is possible to change the specified functions except for
the general-purposed I/O with the I/O parameters. [Refer to the instruction manual for the XSEL-R/S/
RX/SX/RXD/SXD controller for more information.]
Input Port Output Port
Port No. Function Port No. Function
000 Program Start 300 Alarm Output
001 Universal Input 301 Ready Output
002 Universal Input 302 Emergency Stop Output
003 Universal Input 303 Universal Output
004 Universal Input 304 Universal Output
005 Universal Input 305 Universal Output
006 Universal Input 306 Universal Output
007 Program
Specification (LSB) 307 Universal Output
008 Program
Specification Startup
program to
be indicated
with binary 308 Universal Output
009 Program
Specification 309 Universal Output
010 Program
Specification 310 Universal Output
011 Program
Specification 311 Universal Output
012 Program
Specification 312 Universal Output
013 Program
Specification (MSB) 313 Universal Output
014 Universal Input 314 Universal Output
015 Universal Input 315 Universal Output
·
·
·
·
·
·
·
·
·
·
·
·
Note The number of standard I/O ports is;
● Input 000 to 299 (MAX 300 points)
● Output 300 to 599 (MAX 300 points)
Be careful of the number of I/O ports when using CC-Link and PIO together.
