94

5. T

abletop Robot TT

4.6 Data in remote registers

Addresses in PLC are assigned to the remote I/O addresses and remote register areas that correspond to

the station number set on the CC-Link board and the number of occupied stations set by the PLC parameter,

in steps of 16 points (one word) in order of TT port number.

Setting the I/O parameter No. 120 to “0” allows the data in one word to be transmitted by reversing the

order of the higher-order byte (higher-order 8 bits) and the lower-order byte (lower-order 8 bits) in the

communications area with the PLC remote register. (Remote I/O areas are not changed.)

I/O parameters

No. Parameter

name

Default

(reference)

Input range

Remarks

120 Network attribute 1

1

0H – FFFFFFFFH Bit

0-3: CC-Link remote register area H/L

byte

SWAP selection (0: No SWAP, 1: SWAP)

* There should not be inconsistencies between the port numbers of I/O

parameters No. 14 and No. 15 and the number of occupied stations.

The relationships between I/O signals are shown below by taking s case where the number of I/O points of TT is

set to 112 or more and 192 or less (two stations occupied) for example.

(1)

TT remote I/O areas and remote register areas

Remote input: Port No. 48 to No. 111

Remote output: Port No. 348 to No. 411

Remote address (input): Port No. 112 to No. 239

Remote address (output): Port No. 412 to No. 539

(Note) Since ports No. 128 to No. 143 and No. 428 to No. 443 are the system areas for the remote device stations on

the PLC side, they cannot be used.
