62
4. XSEL-R/S/RX/SX/RXD/SXD
[1] Network Setting Check
Confirm that the 2nd digit of I/O Parameter No. 25 Network I/F Module Control setting is showing
“1” (CC-Link).
No. Parameter name Default Input Range Unit Remarks
225
Network I/F
Module Control
1* 10H to 13H -
bits 4-7(2 nd digit):
Network I/F Module 2type
0: Not Mounted
1:CC-Link
2:DeviceNet
3:PROFIBUS
[2] I/O Port Allocation Type
I/O Parameter No.1 Set I/O Port Assignment Classification.
No. Parameter name Default Input Range Unit Remarks
1
I/O Port Assignment
Classification Setting
(Note)
1 0 to 1 -
0: Fixed Allocation
1: Automatic Allocation
x
Reference Priority of I/O Port
Assignment when
automatically assigned
1) to Port Number
(No.0 to 299/No.300 to
599)
2) Network I/F Module1
3) I/Oslot 1(I/O1) Mounting
board
4) I/Oslot 2(I/O2) Mounting
board
* I/Oslot 1(I/O1) Assigned for
the continuously mounted
range from mounting board
x
Reference Priority of I/O Port
Assignment when
automatically assigned
1) to Port Number
(No.1000 to 3999/No.4000
tp 6999)
2) Network I/F Module 2
3) Expansion I/O unit
4) IA Net
Note If the automatic assignment is selected, the input port is assigned to an extension
input port domain (No. 1000 to 3999). The output port is assigned to an extension
output port domain (No. 4000 to 6999).
If the fixed assignment is selected, the user will manually assign the input to either of the
standard input port domain (No. 0 to 299) or extension input port domain (No. 1000 to
3999). For the output port, the user will manually assign the output to either the standard
output port domain (No. 300 to 599) or the extension output port domain
(No. 4000 to
6999).
Reference
Priority of I/O Port
Assignment when
automatically assigned
Port Number
(No.0 to 299/No.300 to 599)
1) Network I/F Module1
2) I/O slot 1 (I/O1) Mounting
board
3) I/O slot 2 (I/O2) Mounting
board
* I/O slot 1 (I/O1) Assigned for
the continuously mounted
range from mounting board
1)
2)
3)
Reference
Priority of extension I/O ports
at automatic assignment
Port Number
(No.1000 to 3999/No.4000 to
6999)
Confirm that the 2nd digit of I/O Parameter No. 225 Network I/F Module Control setting is
showing “1” (CC-Link).
I/O Port Allocation Type Setting
Note If the automatic assignment is selected, the input port is assigned to an extension
input port area (No. 1000 to 3999). The output port is assigned to an extension
output port area (No. 4000 to 6999).
If the fixed assignment is selected, the user will manually assign the input to either
of the standard input port area (No. 0 to 299) or extension input port area (No. 1000
to 3999).
For the output port, the user will manually assign the output to either the standard
output port area (No. 300 to 599) or the extension output port area (No. 4000 to
6999).
