19
3. X-SEL-J/K/P/Q/JX/KX/PX/QX
(2)
Factory-configured parameters of J/K type (standard setting)
No. Parameter
name
Input
range
Set
value
Remarks
1
I/O port assignment type
0 – 20
1
0: Fixed assignment
1: Automatic assignment (Priority: slot 1
)
* The ports only in the continuous installation
range from slot 1 are assigned for safety.)
2 Standard
I/O:
Input port start No. (I/O 1)
-1 – 599
000
0 + (multiples of 8) (Invalid for negative values)
3 Standard
I/O:
Output port start No. (I/O 1)
-1 – 599
300
300 + (multiples of 8)
(Invalid for negative values)
4
Expansion I/O 1 fixed assignment
time: Input port start No. (I/O 2)
-1 – 599
-1
0 + (multiples of 8) (Invalid for negative values)
(Slot next to the standard I/O)
5
Expansion I/O 1 fixed assignment
time: Output port start No. (I/O 2)
-1 – 599
-1
300 + (multiples of 8)
(Invalid for negative values)
6
Expansion I/O 2 fixed assignment
time: Input port start No. (I/O 3)
-1 – 599
-1
0 + (multiples of 8) (Invalid for negative values)
7
Expansion I/O 2 fixed assignment
time: Output port start No. (I/O 3)
-1 – 599
-1
300 + (multiples of 8)
(Invalid for negative values)
8
Expansion I/O 3 fixed assignment
time: Input port start No. (I/O 4)
-1 – 599
-1
0 + (multiples of 8) (Invalid for negative values)
9
Expansion I/O 3 fixed assignment
time: Output port start No. (I/O 4)
-1 – 599
-1
300 + (multiples of 8)
(Invalid for negative values)
10 Standard I/O error monitoring (I/O 1)
0 – 5
2
11 Expansion I/O 1 error monitoring (I/O
2)
0 – 5
0
12 Expansion I/O 2 error monitoring (I/O
3)
0 – 5
0
13 Expansion I/O 3 error monitoring (I/O
4)
0 – 5
0
0: Non-monitoring
1: Monitoring
2: Monitoring (Non-monitoring of 24V I/O power
related errors)
(Main application of Ver. 0.55 or later)
3: Monitoring (Monitoring of 24V I/O power related
errors only)
(Main application of Ver. 0.55 or later)
14 Network I/F card remote:
Number of ports used for input
0 – 256
64
Multiples of 16
15 Network I/F card remote:
Number of ports used for output
0 – 256
64
Multiples of 16
(I/O 1) to (I/O 4) indicate the slot numbers.
