7. SCON-C
(2) Rotary switches
The following can be carried out by rotary switches:
a. Setting of station number
b. Setting of communications speed
a. Setting of station number
In the CC-Link only with remote I/O stations, up to 64 units can be connected.
The station number is set in the 1 to 64 range by the two rotary switches.
SA u 10: Sets the tens place.
SA u 1: Sets the ones place.
Station number
Rotary switch selection
number
SA u 10 SA u 1
0 0 0
1 10 1
2 20 2
3 30 3
4 40 4
5 50 5
6 60 6
7
 7
8
 8
9  9
(Example) When setting the station number to 12:
Set the rotary switch SA
u 10 to 1.
Set the rotary switch SA
u 1 to 2.
(Note) The CC-Link first I/O address in PLC is determined according to the master unit installation position and the number of
I/O occupied points of the unit installed prior to that.
The I/O addresses in PLC are assigned from the first I/O address above in order of station number.
For further information regarding setting of the station number and setting of the I/O address in the PLC, refer to the
Operation Manuals for the master unit and PLC to be mounted.
