106
6. RCS-C and E-Con
b. Setting of communications speed
The communications speed is set by the rotary switch BR.
Rotary switch selection number Communications speed
0 156 kbps
1 625 kbps
2 2.5 Mbps
3 5 Mbps
4 10 Mbps
Setting to 5 or more prohibited Error
(3) Display of monitor LEDs
The four LEDs mounted on the front of the board can indicate the board operating state and network
condition.
LED Color
Display
condition
Display details (display indication)
RUN Green Lighting
Lights when communications start and turns off when
communications are interrupted for a fixed time or
longer.
SD Green Lighting Lights during data transmission
RD Green Lighting Lights during data reception
Lighting Local station address receiving data has an error.
ERR Red
Flashing
Setting by the communications speed setting rotary
switch was changed during communications.
Setting by the station number setting rotary switch
was changed during communications.
