9. Communications with Master station
8.2 Remote register
(1)
Master station ĸ X-SEL (Remote device station)
Four words are used for one station.
Master station
RCS-C/E-Con/SCON/X-SEL
Remote I/O station
(Station No. 1: one station
occupied)
X-SEL
Remote device station
(Station No. 2: Two
stations occupied)
Buffer address
For station 1
Remote register
For station 2
For station 3
For station 4
For station 5
For station 6
For station 7
For station 8
Output port No.
