Page 140

132
8.
ASEL, PSEL, SSEL
ṄIn the case that the setting for the I/O Point is 112 points or larger and 192 points or smaller:
The addresses in the PLC, are allocated in the order of port No., to the remote I/O addresses and
remote register corresponding to the set station No. and the No. of occupied stations set using the PLC
parameters.
(1) Remote I/O
Xnn/Ynn shows the remote I/O address in the PLC corresponding to the station No.
The addresses for the PLC remote I/O (RX/RY) are set as Xnn/Ynn. (Refer to “9. Communication with the
Master Station”).
Reference
(Input)
(Input)
(Output)
(Output)
Port No.
Port No.
ASEL, PSEL, SSEL
