4. XSEL-R/S/RX/SX/RXD/SXD
(2) Example for when using CC-Link and I/O Board 1 together
It is how to establish the setting when using CC-Link to 256 ports of each input and output from the top
of the extended I/O ports and assigning the I/O board (48 ports for each input and output) to the
standard I/O ports.
Extended Input Ports No.1000 to 1255
Standard Input Port No.0 to 47
Extended Output Ports No.4000 to 4255 Standard Output Port No.300 to 347
(CC-Link board)
(I/O board)
Ɣ I/O Parameters
No.
Parameter name
Default
(Reference)
Input
Range
Unit
Remarks
1
I/O
Port
Allocation Type
1
0 to 1
0
0: Fixed Allocation
1: Automatic Allocation
x
Reference 1 Priority of I/O Port
Assignment when automatically
assigned
1) to Port Number
(No.0 to 299/No.300 to 599)
2) No. of Network I/F Module 1
3) I/Oslot 1(I/O1) Mounting board
4) I/Oslot 2(I/O2) Mounting board
* I/Oslot 1(I/O1) Assigned for the
continuously mounted range from
mounting board
x
Reference 1 Priority of I/O Port
Assignment when automatically
assigned
1) to Port Number
(No.1000 to 3999/No.4000 to
6999)
2) No. of Network I/F Module 2
3) Expansion I/O unit
4) IA Net
2
Standard I/O Fix-Allocated
Input Port Start No
0
-1 to 599
0
0+(Multiples of 8)
[Ineffective when -1 is selected]
3
Standard I/O Fix-Allocated
Input Port Start No
300
-1 to 599
300
300+(Multiples of 8)
[Ineffective when -1 is selected]
1)
2)
3)
1)
2)
3)
Reference 2
Priority of extension
I/O ports at automatic assignment
Port Number
(No.1000 to 3999/No.4000 to
6999)
Reference 1
Priority of I/O Port Assignment
when automatically assigned
Port Number
(No.0 to 299/No.300 to 599)
It is how to establish the setting when using CC-Link to 256 points of each input and output from the
top of the extended I/O ports and assigning the I/O board (48 points for each input and output) to the
standard I/O ports.
I/O Port Allocation Type
Standard I/O Fix-Allocated
Output Port Start No.
Standard I/O Fix-Allocated
Input Port Start No.
1) Network I/F Module 1
2) I/O slot 1 (I/O1) Mounting board
3) I/O slot 2 (I/O2) Mounting board
* I/O slot 1 (I/O1) Assigned for the
continuously mounted range from
mounting board
1) Network I/F Module 2
2) Expansion I/O unit
3) IA Net
0+ (Multiples of 8)
[Ineffective when -1 is selected]
300+ (Multiples of 8)
[Ineffective when -1 is selected]
