10. Common Items and Others

9. Common Items and Others

9.1 Communications

cable

For CC-Link communications cable,

CC-Link Ver.1.10 compatible dedicated cable

(FANC-SBH, FANC-SB, etc.,) is used.

9.2 Connection of communications cable connector

Connect the communications cable according to the following connector table:

Pin No.

Signal name

Application

1 DA

Communications

line

2 DB

Communications

line

3 DG

Ground

4 SLD

Shield

5 FG

Ground

SLD and FG are internally connected.

The communications cable is connected to pin No. 1 to No. 4.

9.3 Terminators

It is required to connect a terminator to the units at each end of the CC-Link system.

Connect it between DA and DB of the connector.

Terminators are attached to each controller of X-SEL, ASEL, PSEL, SSEL, RCS-C, E-Con, ACON, PCON, and

SCON.

The terminator varies according to the model name of the CC-Link compatible cable as follows:

Cable FANC-SBH: 130

: 1/2W (CC-Link dedicated high performance cable)

Cable FANC-SB: 110

: 1/2W (CC-Link dedicated cable)

(Note) For further information, refer to the Operation Manual for the master unit.
