3. X-SEL-J/K/P/Q/JX/KX/PX/QX
3.1.9 CSP file
When using the GX Configurator-CC (manufactured by Mitsubishi Electric Corporation), download the CSP file
from our Web site shown below if required.
Web site:
http://www.iai-robot.co.jp
The CSP file to be used is different according to the number of ports used (number of I/O ports) set by the I/O
parameters No. 14 and No. 15 of X-SEL.
File name
Description
Number of ports used in X-SEL
(Number of I/O points)
HMS-ABS-CCL_1.csp For one remote device (one station)
96 points or less each
HMS-ABS-CCL_2.csp For two remote devices (two stations)
112 points or more and 192 points or
less each
HMS-ABS-CCL_3.csp For two remote devices (three stations)
208 points or more and 256 points or
less each
For the setting method of the remote station (X-SEL) information to the master station, refer to the Operation
Manuals for the master station, PLC to be mounted, and peripherals.
