2. Interface Specifications
2. Interface Specifications
Item Specification
Communication Protocol
CC-Link Ver1.10
Baud rate [Mbps] 10 / 5 / 2.5 / 0.625 / 0.156
Communication System Broadcast Polling System
Synchronization system Frame synchronization system
Encoding system NRZI
Transmission Path Format Bus format (EIA RS485 conformance)
Transmission format HDLC conformance
Error control system CRC(X16+X12+X5+1)
Number of occupied stations XSEL(except for K Type), ASEL,
PSEL, SSEL, TT
: Remote device station 1 to 3 station
XSEL-K : Remote I/O station 1 station
RCS-C, E-Con, SCON-C : Remote I/O station 1 station
Baud rate
[Mbps]
10 5 2.5 0.625 0.156
Communication
Cable Length
(Note 1) Total Cable
Length [m]
100 160 400 900 1200
Connector (Controller side) (Note 2) XSEL, ASEL, PSEL, SSEL,TT :MSTBA2.5/5-G-5.08AU
RCS-C, E-Con,SCON-C
:MC1.5/5-G-3.81
Manufactured by Phoenix Contact Controller
Note 1 For T branch communication, refer to the Instruction Manuals for the master unit and PLC
to be mounted.
Note 2 The cable-side connector is a standard accessory.
x XSEL-R/S/RX/SX/RXD/SXD, TT : MSTB2.5/5-ST-5.08AU
x XSEL-J/K/JX/KX, SSEL : SMSTB2.5/5-ST-5.08AU
x RCS-C, E-Con, SCON-C
: MC1.5-ST-3.81
Manufactured by Phoenix Contact Controller
