123

8.
ASEL, PSEL, SSEL

7.3 I/O Parameter Setting

Using the I/O parameters, set the Station No., Communication Speed, and I/O port, etc., for ASEL, PSEL or SSEL

used in the CC-Link.

(1) Network

Type

Setting

The I/O Parameter No. 225 “Network I/F Module Control” has been set to “1H” (CC-Link) when the unit is

delivered. (The setting is not necessary)

(2)

Station No. Setting

Using the I/O parameter No.226 "Network I/F Module Communication Attribute 1", set the station No.

The setting range is from 1 to 64. (Already set in system delivery: 1)

Note: When any of the already occupied stations is set to “No. 0” or “No. 65 or larger”, the “D75: Field Bus Parameter

Error” occurs.

(3)

Communication Speed Setting

By selecting one of "Bit 0"through "Bit 3" for the parameter No.227 "Network I/F Module Communication

Attribute 2", set the Communication Speed. The setting range is from 0H to 4H.

I/O Parameter

No.227 Setting value

Communication

Speed [bps]

0 156

K

1 625

K

2 2.5

M

3 5

M

4 10

M

(Already set in system delivery)

(Note) Set the Communication Speed based on that set for the Master Station.
