3. X-SEL-J/K/P/Q/JX/KX/PX/QX
(3) When the number of I/O points is set to 208 or more and 256 or less:
Configured as three remote devices. (Three stations occupied)
I/O parameter
No. 14 No. 15
X-SEL side DI
(Port No.)
PLC side
X-SEL side DO
(Port No.)
PLC side
(16) (16) 000 – 015 RY 0 – F 300 – 315 RX 0 – F
(32) (32) 016 – 031 RY 10 – 1F 316 – 331 RX 10 – 1F
(48) (48) 032 – 047 RY 20 – 2F 332 – 347 RX 20 – 2F
(64) (64) 048 – 063 RY 30 – 3F 348 – 363 RX 30 – 3F
(80) (80) 064 – 079 RY 40 – 4F 364 – 379 RX 40 – 4F
(96) (96) 080 – 095 RY 50 – 5F 380 – 395 RX 50 – 5F
(112) (112) 096 – 111 RWw 0 396 – 411 RWr 0
(128) (128) 112 – 127 RWw 1 412 – 427 RWr 1
(144) (144) 128 – 143 RWw 2 428 – 443 RWr 2
(160) (160) 144 – 159 RWw 3 444 – 459 RWr 3
(176) (176) 160 – 175 RWw 4 460 – 475 RWr 4
(192) (192) 176 – 191 RWw 5 476 – 491 RWr 5
208 208 192 – 207 RWw 6 492 – 507 RWr 6
224 224 208 – 223 RWw 7 508 – 523 RWr 7
240 240 224 – 239 RWw 8 524 – 539 RWr 8
256 256 240 – 255 RWw 9 540 – 555 RWr 9
Not be set - RWw A - RWr A
Not be set - RWw B - RWr B
* Since the shaded portions are the system areas for the remote device station on the PLC side, they
cannot be used as I/O.
* In the case of three stations being occupied, twelve words (ten words for X-SEL) are assigned for each
input and output in the data register on the PLC side. Be careful about overlapping of data register on
the PLC side.
