124
8.
ASEL, PSEL, SSEL
(4) I/O Port Allocation
Using the following I/O parameters, set the physical I/O port quantity and port allocation for ASEL, PSEL or
SSEL, used on the CC-Link system.
No. 1: I/O Port Allocation Type
No. 14: No. of Network I/F Module Remote Input Ports
No. 15: No. of Network I/F Module Remove Output Ports Refere to "7.4" Item.
No. 16: Network I/F Module Fix-Allocated Input Port Start No.
No. 17: Network I/F Module Fix-Allocated Output Port Start No.
Refer to “ASEL, PSEL and SSEL Network Related I/O Parameter List” in the next page for more
information.
(Note) In the ASEL, PSEL and SSLE controller, the following I/O parameters are disabled during the use of the CC-Link
module. Even the setting is performed for such parameters, there is no influence on the No. of ports to be used in
the CC-Link or allocated Port No.
No. 2: Standard I/O Fix-Allocated Input Port Start No. (1/O1)
No. 3: Standard I/O Fix-Allocated Output Port Start No. (1/O1)
No. 10: Standard I/O Error Monitoring
(5) Network Error Monitoring
“Monitoring/Non monitoring” is set using the I/O parameter No. 18 “Network I/F Module Error Monitoring”.
The error confirmation time is set using the “Bit 4” through “Bit 11” for the I/O parameter No. 120 “Network
Attribute 1”. When the network link error is continued more than the time set for parameter No. 120, it is
regarded as a system error.
Refer to “ASEL, PSEL and SSEL Network Related I/O Parameter List” in the next page for more
information.
