4-39 PLS Functions
Backplane
PL-1746 Function Name SLC 500 Mapping Read/ Valid Range for Data
File Index Write
Address Number Capability
Program 25 Shift Counts M0:S.1720- 3568- R/W 0-255
(Channels 0-31) M0:S.1751 3630
Program 26 Shift Counts M0:S.1752- 3632- R/W 0-255
(Channels 0-31) M0:S.1783 3694
Program 27 Shift Counts M0:S.1784- 3696- R/W 0-255
(Channels 0-31) M0:S.1815 3758
Program 28 Shift Counts M0:S.1816- 3760- R/W 0-255
(Channels 0-31) M0:S.1847 3822
Program 29 Shift Counts M0:S.1848- 3824- R/W 0-255
(Channels 0-31) M0:S.1879 3886
Program 30 Shift Counts M0:S.1880- 3888- R/W 0-255
(Channels 0-31) M0:S.1911 3950
Program 31 Shift Counts M0:S.1912- 3952- R/W 0-255
(Channels 0-31) M0:S.1943 4014
Program 32 Shift Counts M0:S.1944- 4016- R/W 0-255
(Channels 0-31) M0:S.1975 4078
Program 33 Shift Counts M0:S.1976- 4080- R/W 0-255
(Channels 0-31) M0:S.2007 4142
Program 34 Shift Counts M0:S.2008- 4144- R/W 0-255
(Channels 0-31) M0:S.2039 4206
Program 35 Shift Counts M0:S.2040- 4208- R/W 0-255
(Channels 0-31) M0:S.2071 4270
Program 36 Shift Counts M0:S.2072- 4272- R/W 0-255
(Channels 0-31) M0:S.2103 4334
Program 37 Shift Counts M0:S.2104- 4336- R/W 0-255
(Channels 0-31) M0:S.2135 4398
Program 38 Shift Counts M0:S.2136- 4400- R/W 0-255
(Channels 0-31) M0:S.2167 4462
Program 39 Shift Counts M0:S.2168- 4464- R/W 0-255
(Channels 0-31) M0:S.2199 4526
Program 40 Shift Counts M0:S.2200- 4528- R/W 0-255
(Channels 0-31) M0:S.2231 4590
Program 41 Shift Counts M0:S.2232 4592- R/W 0-255
(Channels 0-31) M0:S.2263 4654
Program 42 Shift Counts M0:S.2264- 4656- R/W 0-255
(Channels 0-31) M0:S.2295 4718
Program 43 Shift Counts M0:S.2296- 4720- R/W 0-255
(Channels 0-31) M0:S.2327 4782
Program 44 Shift Counts M0:S.2328- 4784- R/W 0-255
(Channels 0-31) M0:S.2359 4846
Program 45 Shift Counts M0:S.2360- 4848- R/W 0-255
(Channels 0-31) M0:S.2391 4910
Program 46 Shift Counts M0:S.2392- 4912- R/W 0-255
(Channels 0-31) M0:S.2423 4974
Program 47 Shift Counts M0:S.2424- 4976- R/W 0-255
(Channels 0-31) M0:S.2455 5038
Shift Count (cont’d)
(continued)
