1-1 Introduction
Configuration Item M0 File PS-6400 Keypad Screen Installations Installations NOT Reference
Using Groups Using Groups Page
and Modes and Modes
Direction of
Increasing Rotation
M0:S.34 DIR OF ROTATION x x 4-4
Scale Factor M0:S.32 SCALE FACTOR x x 4-37
Machine Position M0:S.24 MACHINE OFFSET 4-14
Keyboard Quantity M0:S.48 KEYBOARD QTY x x 4-13
PS-4108 I/O
Rack Quantity
M0:S.56 RACK QTY x x 4-34
Analog Output
Module Quantity
M0:S.40 ANALOG QTY x x 4-2
Number of
Output Groups
M0:S.64 OUTPUT GROUPS x x 4-20
Resolver Mode
(Master/Slave)
M0:S.60 RESOLVER MODE x x 4-36
Group Channel M0:S.66 -
Quantities M0:S.71 OUTPUT GROUPS x 4-20
Group Modes M0:S.82 -
M0:S.87
OUTPUT GROUPS x 4-20
Group Offsets M0:S.74 -
M0:S.79
GROUP OFFSET x 4-8
Group Position
Display Mode
M0:S.65 GRP POS DISP x 4-10
PL-1746 QUICK START
1. Set PL-1746, PS-4108, and PS-6400 DIP switches as described in Chapter 2.
2. Mount all external equipment. This includes as much of the following equipment as the particular installation
requires. See Chapter 2 for installation details.
• Electro Cam Corp. Resolver
• PS-6400 Keypad/Display
• I/O power supply (provides power to the front of the PL-1746 module)
• PS-4108 I/O rack (s)
• Solid State Relays installed into PS-4108 I/O rack (s)
3. Plug the PL-1746 module into the SLC chassis.
4. Cable all external equipment to the PL-1746 module.
• Electro Cam Corp. Resolver
• PS-6400 Keypad/Display
• I/O power supply (provides power to the front of the PL-1746 module)
• PS-4108 I/O rack (s)
5. In Rockwell programming software, ensure that the PL-1746 module’s card type is set to OTHER, with ID#
13235.
6. In Rockwell programming software, set the PL-1746 module’s M0 file length to 16320 and its M1 file length
to 16380.
7. Configure the PL-1746 module. Enter as many of the indicated configuration items as apply to the particular
installation. This may be done via the M0 File or via the PS-6400 Keypad/Display screens.
8. Program PL-1746 pulses.
9. Program PL-1746 advanced features. This includes any advanced features to be used in the particular installa-
tion: speed compensation, timed outputs, motion ANDing, and so forth.
