3-13 How to Program the PLS
PL-1746 Function Name SLC 500 Mapping Read/ Valid Range for Data Reference
File Index Write Page
Address Number Capability
System
Model
M0:S.0 128 R/O 1746 4-17
Options M0:S.2 132 R/O 0 = Standard, 1 = Shift Register 4-17
Base Revision M0:S.4 136 R/O 0-32767 4-43
Major Revision M0:S.3 134 R/O 0-32767 4-43
Keyboard Quantity M0:S.48 224 R/W 0-2 4-13
Rack Quantity M0:S.56 240 R/W 0-2 Model C01 4-34
0 Models C02,C03,C04
Default Program M0:S.120 368 R/W 0-47 4-4
EEPROM Checksum M0:S.5 138 R/O -32768 to 32767 4-5
Models C02,C03 only
EEPROM Checksum
M0:S.6 140 R/W 0=Done 4-5
Command/Status 1=Execute/Busy
Models C02,C03 only
Output Quantity
M0:S.1 130 R/O 32
Pulses Total M0:S.26 180 R/O 1252 Units without Shift Register 4-29
(no -S in model #)
787 Units with Shift Register
(-S in model #)
Pulses Used M0:S.27 182 R/O 0 to Pulses Total 4-29
Backplane Interlock M0:S.866 1860 R/W 0=Done 3-1
1=Execute/Busy
Timed Outputs
Time (ms)
M0:S.320- 768- R/W 0-9999 4-45
Channels 0-31, M0:S.351 830
1word/channel
Quick Reference
