3-10 How to Program the PLS
PL-1746 Function Name SLC 500 Mapping Read/ Valid Range for Data Reference
File Index Write Page
Address Number Capability
Commands (bits 4-1):
0000 Read
0001 Write
0010 Increment On
0011 Decrement On
0100 Increment Off
0101 Decrement Off
0110 Increment Both
0111 Decrement Both
1000 Increment All
1001 Decrement All
1010 Change On
1011 Change Off
1100 Reserved
1101 Reserved
1110 Reserved
1111 Reserved
Pulses (Bulk Pulse Storage in M1 File)
Pulse Number M1:S.A 32768+8 R/O 1-1252Models C01,C04
(P is the Pulse Number.) where
×
(P-1) 1-787Models C02,C03
A = 4 Note: A pulse number 0
×
(P-1) indicates an invalid pulse.
Pulse Program/Channel M1:S.B 32768+8 R/O Program: 0-47
Program in high byte where
×
(P-1)+2 Channel: 0-31
Channel in low byte B= 4
×
(P-1)+1
Pulse On M1:S.C 32768+8 R/O 0 to (Scale Factor-1)
where
×
(P-1)+4
C= 4
×
(P-1)+2
Pulse Off M1:S.D 32768+8 R/O 0 to (Scale Factor-1)
where
×
(P-1)+6
D = 4
×
(P-1)+3
Rate Display
RPM Update Rate
M0:S.49 226 R/W 0=1/s 1=2/s 2=10/s 4-36
Toggle RPM M0:S.50 228 R/W 0-9999 4-46
Displayed Units M0:S.51 230 R/W 0=RPM 1=BPM 2=CPM 3=IPM 4-35
Decimal Point Location M0:S.52 232 R/W 0-3 4-35
Rate Multiplier M0:S.53 234 R/W 1-1091 4-35
Rate Divisor M0:S.54 236 R/W 1-63 4-35
Resolver
Direction of Rotation
M0:S.34 196 R/W* 0=CCW 1=CW 4-4
Machine Offset M0:S.33 194 R/W* 0 to (Scale Factor-1) 4-14
Machine Position M0:S.24 176 R/W* 0 to (Scale Factor-1) 4-14
Resolver Mode M0:S.60 248 R/W* (-C01) 0=Master 1=Slave 4-36
R/O models C02,C03, C04 (set via DIP Switch)
Resolver Position M0:S.23 174 R/O 0 to (Scale Factor-1) 4-14
Resolver Speed M0:S.22 172 R/O 0-3000 4-15
Scale Factor M0:S.32 192 R/W* 2-4096 Resolver-Based Units 4-37
(-R in model #)
2-4000 Encoder-Based Units
(-E in model #)
