4-27 PLS Functions
Pulse Copy
Backplane
PL-1746 Function Name SLC 500 Mapping Read/ Valid Range for Data
File Index Write
Address Number Capability
Pulse Copy Program M0:S.704 1536 R/W 0-47
Pulse Copy Channel M0:S.705 1538 R/W 0-31
Pulse Copy On (Train Start) M0:S.706 1540 R/W 0 to (Scale Factor-1)
Pulse Copy Off (Train End) M0:S.707 1542 R/W 0 to (Scale Factor-1)
Pulse Copy Count M0:S.708 1544 R/W 1 to ((Off-On)/2)
(Number of Pulses)
Pulse Copy Duration (of each pulse) M0:S.709
1546 R/W 1 to ((Off-On)/2*Count)
Pulse Copy Command/Status M0:S.710 1548 R/W* Bit 15 Error
*Not while Bit 14 Program Error
running Bit 13 Channel Error
Bit 12 On > Scale Factor Error
Bit 11 Off > Scale Factor Error
Bit 10 Overlap Error
Bit 9 Duration Error
Bit 8 Reserved Bits Error
Bit 7-1 Reserved
Bit 0 Execute/Busy
M0:S.710/0 Execute Pulse Copy. This bit remains on until the copy is complete
or an error occurs. Either condition will clear this bit.
M0:S.710/1-7 Reserved bits. Writing a one to any of these bits will cause a reserved
bits error (see M0:S.710/8).
M0:S.710/8 Reserved bits. This bit is set if a one is written to any of the reserved
bits.
M0:S.710/9 The Duration Error bit is set if the pulse duration is < 1.
M0:S.710/10 The Overlap Error bit is set if the number of pulses created exceeds
one half the scale factor, which would cause pulses to be overlapped.
M0:S.710/11 The Off Pulse Copy value exceeds the scale factor.
M0:S.710/12 The On Pulse Copy value exceeds the scale factor.
M0:S.710/13 The channel error bit is set if channel value is out of range.
M0:S.710/14 The program error bit is set if program value is out of range.
M0:S.710/15 The Error bit is set if any of the above errors is set. This provides a
single bit to test for command success/failure. When the Error bit is
set, test the other bits to determine the exact cause.
When the error bit M0:S.710/15 is set, the Command Error bit and the Any Error bit
are set in the Progamming Error Register (I:S.7). To clear the error condition, toggle
Clear Error bit (O:S.0/8) ON. No additional commands will be accepted until the error
bits are cleared.
(continued)
