4-38 PLS Functions
Backplane
PL-1746 Function Name SLC 500 Mapping Read/ Valid Range for Data
File Index Write
Address Number Capability
Shift Register Models C02,C03 only
Program 0 Shift Counts M0:S.920- 1968- R/W 0-255
(Channels 0-31) M0:S.951 2030
Program 1 Shift Counts M0:S.952- 2032- R/W 0-255
(Channels 0-31) M0:S.983 2094
Program 2 Shift Counts M0:S.984- 2096- R/W 0-255
(Channels 0-31) M0:S.1015 2158
Program 3 Shift Counts M0:S.1016- 2160- R/W 0-255
(Channels 0-31) M0:S.1047 2222
Program 4 Shift Counts M0:S.1048- 2224- R/W 0-255
(Channels 0-31) M0:S.1079 2286
Program 5 Shift Counts M0:S.1080- 2288- R/W 0-255
(Channels 0-31) M0:S.1111 2350
Program 6 Shift Counts M0:S.1112- 2352- R/W 0-255
(Channels 0-31) M0:S.1143 2414
Program 7 Shift Counts M0:S.1144- 2416- R/W 0-255
(Channels 0-31) M0:S.1175 2478
Program 8 Shift Counts M0:S.1176- 2480- R/W 0-255
(Channels 0-31) M0:S.1207 2542
Program 9 Shift Counts M0:S.1208- 2544- R/W 0-255
(Channels 0-31) M0:S.1239 2606
Program 10 Shift Counts M0:S.1240- 2608- R/W 0-255
(Channels 0-31) M0:S.1271 2670
Program 11 Shift Counts M0:S.1272- 2672- R/W 0-255
(Channels 0-31) M0:S.1303 2734
Program 12 Shift Counts M0:S.1304- 2736- R/W 0-255
(Channels 0-31) M0:S.1335 2798
Program 13 Shift Counts M0:S.1336- 2800- R/W 0-255
(Channels 0-31) M0:S.1367 2862
Program 14 Shift Counts M0:S.1368- 2864- R/W 0-255
(Channels 0-31) M0:S.1399 2926
Program 15 Shift Counts M0:S.1400- 2928- R/W 0-255
(Channels 0-31) M0:S.1431 2990
Program 16 Shift Counts M0:S.1432- 2992- R/W 0-255
(Channels 0-31) M0:S.1463 3054
Program 17 Shift Counts M0:S.1464- 3056- R/W 0-255
(Channels 0-31) M0:S.1495 3118
Program 18 Shift Counts M0:S.1496- 3120- R/W 0-255
(Channels 0-31) M0:S.1527 3182
Program 19 Shift Counts M0:S.1528- 3184- R/W 0-255
(Channels 0-31) M0:S.1559 3246
Program 20 Shift Counts M0:S.1560- 3248- R/W 0-255
(Channels 0-31) M0:S.1591 3310
Program 21 Shift Counts M0:S.1592- 3312- R/W 0-255
(Channels 0-31) M0:S.1623 3374
Program 22 Shift Counts M0:S.1624- 3376- R/W 0-255
(Channels 0-31) M0:S.1655 3438
Program 23 Shift Counts M0:S.1656- 3440- R/W 0-255
(Channels 0-31) M0:S.1687 3502
Program 24 Shift Counts M0:S.1688- 3504- R/W 0-255
(Channels 0-31) M0:S.1719 3566
Shift Count
