4-6 PLS Functions
Programming Access
Levels for Function
s
PROGRAMMING LEVEL
Normal
Menu Item Access Display Operator Setup Master
Password Enter Enter Enter Program
Pulses View Program 1 Program Program
Function Menu
Speed Comp View Program 1 Program Program
Timed Outputs View Program 1 Program Program
Analog Output View Program 1 Program Program
Pulse Copy View --- Program Program
Program Copy View --- Program Program
Default Program View Program 1 Program Program
Channel Copy View --- Program Program
Shift Position View Program 1 Program Program
Config Menu
Initial Setup
Dir of Rotation --- --- --- Program
Scale Factor --- --- --- Program
Machine Offset View Program 1 Program Program
Speed Comp Mode --- --- --- Program
Motion Detection View Program 1 Program Program
Motion ANDing --- --- --- Program
Outp Enable ANDing --- --- --- Program
Output Groups --- --- --- Program
Group Position Display --- --- --- Program
Group Offset View Program 1 Program Program
Output Assign --- --- --- Program
Secondary Setup
Keyboard Qty --- --- --- Program 2
Analog Qty --- --- --- Program
Rack Qty --- --- --- Program
Resolver Mode --- --- --- Program
Rate Setup --- --- --- Program
Toggle RPM --- --- --- Program
RPM Update Rate --- --- --- Program
Shift Count --- --- --- Program
Shift Window --- --- --- Program
Test Menu
I/O Status Menu
Input Status View View View View
Output Status View View Force Force
Shift Register View View View View
System Info Menu
Pulse Use View View View View
Software Version View View View View
Model & Options View View View View
EEPROM Checksum View View View View
Heap Status View View View View
Memory Tests --- --- --- Run
System Tests
Program Enable Menu
Enable Codes --- --- --- Program
Per Chn Enable --- --- --- Program
Enable Options
Pulses --- --- --- Program
Speed Comp --- --- --- Program
Timed Outputs --- --- --- Program
Analog Output --- --- --- Program
Motion Detect --- --- --- Program
Default Program --- --- --- Program
Group Offset --- --- --- Program
Machine Offset --- --- --- Program
Mapping Registers
Input Maps --- --- --- Program
Output Maps --- --- --- Program
Interrupt Menu
Interrupt Level --- --- --- Program
Interrupt Enable --- --- --- Program
Enable Codes (cont’d)
1 Can be programmed only if
specified through Per Channel
Enable and Enable Options.
2 Keyboard Quantity can be
programmed only through the
keypad whose address is “0”.
