4-29 PLS Functions
PROGRAM:---< Program to add pulses to;
Enter number, then SEL to go to next screen
CHANNEL:---< Channel to add pulses to;
Enter number, then SEL to go to next screen
ON: 0< "On" time of leading edge of first pulse;
Enter 0, then ENT & SEL to go to next screen
OFF:950< "Off" time of trailing edge of last pulse;
Enter 950, then ENT & SEL to go to next screen
COUNT 10< Total number of pulses to be added;
Enter 10, then ENT & SEL to go to next screen
DURATION: 50< Duration of each pulse added;
Enter 50, then ENT & SEL to go to next screen
DURATION: 50
EXECUTE< Move cursor to EXECUTE, then press SEL to
generate pulses.
DURATION: 35
COMPLETE< COMPLETE indicates pulses have been generated
<-P-> CH: 1 ON: 0 OF: 50
Move cursor to OF and use arrow keys to
review pulse setpoints
Go to SETPOINTS to confirm the pulse train:
Pulses Used
Backplane
PL-1746 Function Name SLC 500 Mapping Read/ Valid Range for Data
File Index Write
Address Number Capability
Pulses Total M0:S.26 180 R/O 1252 Units without Shift Register
(no -S in model #)
787 Units with Shift Register
(-S in model #)
Pulses Used M0:S.27 182 R/O 0 to Pulses Total
Screen MAIN SCREEN to TEST MENU to SYSTEM INFO to PULSES
USED
TOTAL: 1200
USED: 64 Total number of pulses available for programming
Number of pulses programmed into all channels
of all programs
Description The number of pulses shown as "Used" is the sum of all pulses that are programmed
into all channels of all programs. The "Total" value is the number of pulses that can be
stored in non-volatile EEPROM memory. The difference between the two numbers is
the number of pulses available for programming. The number of pulses programmed
into all channels of all programs cannot exceed the value displayed as Total. There
are no values that can be changed in this screen.
Pulse Copy (cont’d)
