3-5 How to Program the PLS
PL-1746 Quick Reference (Applies to all PL-1746 models, except as noted)
Revised 6-9-00
Notes:
1.I/O Module ID Code: Local = 13235, Remote = 3535
2.M0 file size = 16320. M1 file size = 16380.
3Mapping Index Number for M0 file: (Address * 2) + 128.
4.Registers in the M0 file are not contiguous; space has been left between register groups for future expansion. To maintain future
compatibility, SLC programs should not access unlisted registers; writes to these registers result in Illegal Function Errors.
5.In the Read/Write Capability column, R/W means Read/Write, R/O means Read-Only, W/O means Write-Only, and starred
items cannot be written while the resolver/encoder is in motion.
PL-1746 Function Name SLC 500 Mapping Read/ Valid Range for Data Reference
File Index Write Page
Address Number Capability
Analog Outputs
Analog Quantity
M0:S.40 208 R/W 0-2 Model C01 4-2
(Real-World Outputs) R/O 0 Models C02,C03,C04
Analog Output 1 Offset M0:S.41 210 R/W 0-4095 4-1
Analog Output 1 High RPM M0:S.42 212 R/W 0-3000 4-1
Analog Output 1 Value M0:S.43 214 R/O 0-4095 4-1
Analog Output 2 Offset M0:S.44 216 R/W 0-4095 4-1
Analog Output 2 High RPM M0:S.45 218 R/W 0-3000 4-1
Analog Output 2 Value M0:S.46 220 R/O 0-4095 4-1
Channel Copy
Channel Copy Source Program
M0:S.800 1728 R/W* 0-47 4-2
Channel Copy Source Channel M0:S.802 1732 R/W* 0-31 4-2
Channel Copy Destination Program M0:S.801 1730 R/W* 0-47 4-2
Channel Copy Destination Channel M0:S.803 1734 R/W* 0-31 4-2
Channel Copy Command/Status M0:S.804 1736 R/W* Bit 15 Error 4-2
Bit 14 Source Pgm Error
Bit 13 Dest Pgm Error
Bit 12 Source Chn Error
Bit 11 Dest Chn Error
Bit 10 Reserved Bits Error
Bit 9 Dest Chn Not Empty Erro
Bit 8-1 Reserved
Bit 0 Execute/Busy
Input File
Input Word 0
I:S.0 None R/O 0=Off 4-23
PL-1746 Output Channel 1=On
0-15 Status, 1bit/channel
Input Word 1 I:S.1 None R/O 0=Off 4-23
PL-1746 Output Channel 1=On
16-31 Status, 1bit/channel
Input Word 2
I:S.2 None R/O -32768 to 32767 3-1
Input Word 3 I:S.3 None R/O -32768 to 32767 3-1
Input Word 4 I:S.4 None R/O -32768 to 32767 3-1
