3-8 How to Program the PLS
PL-1746 Function Name SLC 500 Mapping Read/ Valid Range for Data Reference
File Index Write Page
Address Number Capability
Output Word 1 O:S.1 None W/O 0-47 4-15
Active Program
Output Word 2
O:S.2 None W/O -32768 to 32767 3-1
Output Word 3 O:S.3 None W/O -32768 to 32767 3-1
Output Word 4 O:S.4 None W/O -32768 to 32767 3-1
Output Word 5 O:S.5 None W/O -32768 to 32767 3-1
Output Word 6 O:S.6 None W/O -32768 to 32767 3-1
Output Word 7 O:S.7 None W/O -32768 to 32767 3-1
Output Mapping Registers
Output Word 0 Map #
M0:S.192 512 R/W 0-32767 3-4, 4-22
Output Word 1 Map # M0:S.193 514 R/W 0-32767 3-4, 4-22
Output Word 2 Map # M0:S.194 516 R/W 0-32767 3-4, 4-22
Output Word 3 Map # M0:S.195 518 R/W 0-32767 3-4, 4-22
Output Word 4 Map # M0:S.196 520 R/W 0-32767 3-4, 4-22
Output Word 5 Map # M0:S.197 522 R/W 0-32767 3-4, 4-22
Output Word 6 Map # M0:S.198 524 R/W 0-32767 3-4, 4-22
Output Word 7 Map # M0:S.199 526 R/W 0-32767 3-4, 4-22
Output Status
Force Outputs On
M0:S.256- 640- R/W 1=Force Active 4-23
Channels 0-31, 1bit/channel M0:S.257 642 0=Force Inactive
Force Outputs Off M0:S.264- 656- R/W 1=Force Active 4-23
Channels 0-31, 1bit/channel M0:S.265 658 0=Force Inactive
Motion ANDing/Detection
Motion Level 1
M0:S.96 320 R/W 0 to (ML1H-1) 4-18
Low Limit (ML1L)
Motion Level 1
M0:S.97 322 R/W (ML1L+1) to 3000 4-18
High Limit (ML1H)
Motion Level 2
M0:S.98 324 R/W 0 to (ML2H-1) 4-18
Low Limit (ML2L)
Motion Level 2
M0:S.99 326 R/W (ML2L+1) to 3000 4-18
High Limit (ML2H)
Motion ANDing
M0:S.512- 1152- R/W* 0=OFF 4-17
Channels 0-31, 1word/channel M0:S.543 1214 1=ML1
2=ML2
Program Copy
Program Copy Destination Program M0:S.769
1666 R/W* 0-47 4-25
Program Copy Source Program M0:S.768 1664 R/W* 0-47 4-25
Program Copy Command/Status M0:S.770 1668 R/W* Bit 15 Error 4-25
Bit 14 Source Pgm Error
Bit 13 Dest Pgm Error
Bit 12 Reserved Bits Error
Bit 11 Dest Pgm Not Empty Error
Bit 10-1 Reserved
Bit 0 Execute/Busy
Quick Reference
