4-7 PLS Functions
Enable Options
Backplane
PL-1746 Function Name SLC 500 Mapping Read/ Valid Range for Data
File Index Write
Address Number Capability
Operator Enable Options M0:S.107 342 R/W Bit 15-8 Reserved
Bit 7 Machine Offset
Bit 6 Group Offset
Bit 5 Default Program
Bit 4 Motion Detect/ANDing
Bit 3 Analog Outputs
Bit 2 Timed Outputs
Bit 1 Speed Comp
Bit 0 Pulses
Screen MAIN SCREEN to PGM ENABLE MENU to ENABLE OPTIONS
SETPOINTS<
ENABLE: ON
Press the Up Cursor and Down Cursor keys to select the function you wish to change.
Press the SEL key to turn Operator access ON or OFF.
Description This screen lists the various items in the SETUP MENU, and allows you to turn Opera-
tor access to those items on or off.
Access to the “on” items will be available only for those output channels that
have been turned ON in PER CHN ENABLE.
Access can be turned on or off for the following SETUP MENU items:
PULSES MOTION DETECT
DEFAULT PROGRAM ANALOG OUTPUTS
SPEED COMP TIMED OUTPUTS
GROUP OFFSET MACHINE OFFSET
Also see PER CHN ENABLE.
