4-22 PLS Functions
Output Maps
Backplane
PL-1746 Function Name SLC 500 Mapping Read/ Valid Range for Data
File Index Write
Address Number Capability
Output Word 0 Map # M0:S.192 512 R/W 0-32767
Output Word 1 Map # M0:S.193 514 R/W 0-32767
Output Word 2 Map # M0:S.194 516 R/W 0-32767
Output Word 3 Map # M0:S.195 518 R/W 0-32767
Output Word 4 Map # M0:S.196 520 R/W 0-32767
Output Word 5 Map # M0:S.197 522 R/W 0-32767
Output Word 6 Map # M0:S.198 524 R/W 0-32767
Output Word 7 Map # M0:S.199 526 R/W 0-32767
Screen MAIN SCREEN to MAPPING MENU to OUTPUT MAP REGS
REG# OUTPUT MAP#
0 0
Use INC/DEC keys to select the desired mapping register. Use select, then the nu-
meric keypad, to enter the mapping index number followed by the ENT key. See the
section on Remote I/O and Register Mapping for more information. These registers
allow the user to select M0 or M1 file registers for writing through the eight Output file
registers.
Description This screen displays the output mapping registers. When a mapping index number is
placed in one of these registers, the corresponding M0 or M1 register will be mapped
into the indicated output file register.
