2)

From the second menu, select one of the two available ports on the two-wire
interface module:

Slot 1/Port A 2W

Slot 1/Port B 2W

Note:

In this example, the two-wire module has been fitted to slot 1 in the
expansion bay. The expansion bay contains three slots.

2W = Two-wire.

a) To associate one of the four available channels (or to disable channels

associations) with the selected port:
From the third menu (third display screen), select Channel Assign.

b) From the fourth menu, select one of the following:

• Disabled (default)
• Channel A
• Channel B
• Channel C
• Channel D

Note:

When linking is enabled, there will be more than four channels.

c) To confirm the selected setting, press the rotary control.

3)

The Program Output allows a program feed associated with the channel assigned to
the four wire port to either be delivered to that 4 wire port alongside the other channel
audio or not. To set the Program Output:

a) From the third menu, select Program Output.

b) From the fourth menu, select one of the following:

• Unmute (default)
• Mute

4)

To confirm the selected setting, press the rotary control.

5)

Auto-nulling helps to reduce echo while talking on a two-wire audio system. To start
Auto-nulling on the selected port:

a) From the third menu, select Auto-Nulling.

b) From the fourth menu, select Start.

Note:

Auto-nulling is only applicable to two-wire audio. All Talk routes/keys must
be disabled before Auto-nulling can commence. If an echo persists, ensure
all Talk routes are disabled and re-null the system.

60

HelixNet Partyline User Guide
