10.7

Line 1 and 2 LEDs

Note:

This section only applies to the HelixNet Main Station.

The HBP-2X beltpacks, Remote Stations and Speaker Stations are connected by one of the
two lines to the Main Station.

The color of the Line 1 and Line 2 LEDs to the left of the front panel loudspeaker indicate the
service status of each powerline:

Green

LED = Ok.

Amber

LED = Busy.

Red

LED = Error.

For more information:

• About the service status of Lines 1 and 2, see 4.8.3 Viewing powerline information

and status.

• About monitoring system performance and diagnosing system issues on the Main

Station, see 4.8 Diagnostics.

10.8

Line and LAN LEDs

Note:

This section only applies to the HelixNet Remote Station and Speaker Station.

The Remote Station has a line LED that indicates the status of a powerline connection to the
Main Station. The LAN LED indicates the status of the Ethernet connection, if present.

The color of the Line and LAN LEDs to the left of the front panel loudspeaker indicate the
service status of each powerline:

Green

LED = Ok.

Amber

LED = Busy.

Red

LED = Error.

112

HelixNet Partyline User Guide
